STRUCTURE AND CAPABILITY: This kind of hose is made of inner tube (Nylon, reinforcement (High Pressure Synthetic Fiber), and cover (High Flexibility Nylon or Thermoplastic). It is light weight. Flexible and the inner tube is very smooth. With few less of pressure, the hose resistance of the medium flowing is small, and it also owns a fine performance of anti-chemical and impulse.
APPLICATION: Automobile, Engineering Machinery, Lathe, Agriculture Machine, Mining, Spurting the Oil Paint, Avigation & Spaceflight, Cooling and other Hydraulic Control System.
تخصيص
HOSE ID | Hose OD | Working Pressure | Burst Pressure | Minimum Bend Radius | Weight | |||
| Inch | mm | mm | MPa | Psi | MPa | Psi | mm | kg/m |
| 3/16 | 4.8 | 13.1 | 34.5 | 5000 | 137.9 | 20000 | 38 | 0.115 |
| 1/4 | 6.4 | 15.9 | 34.5 | 5000 | 137.9 | 20000 | 51 | 0.176 |
| 3/8 | 9.5 | 19.4 | 27.6 | 4000 | 110.3 | 16000 | 64 | 0.220 |
| 1/2 | 12.7 | 22.7 | 24.1 | 3500 | 96.5 | 14000 | 102 | 0.283 |
SAE 100R8 high pressure thermoplastic hydraulic hose is used in nonconductive applications such as blowout preventers, lube lines and construction machinery. Petroleum based and synthetic hydraulic fluids within -40°F to 212°F are frequently used, which will not cause tube failure in specified temperature range. If working temperature exceeds 212°F, the service life of the hose will materially shorten.
Thermoplastic hydraulic hose in orange cover
Excellent kick resistant;
Non Conductive;
Tight bend radius;
Light weight.
SAE 100R6 (Wrapped Cover / Smooth Cover)
SAE 100R3 (Wrapped Cover / Smooth Cover)
SAE 100 R15 (Wrapped Cover / Smooth Cover)
